P2 Hospital Blood
Pressure Monitor |
| 1.
Anti-Bacteria
Cuff。
2. With data storage function。
3. Equipped with RS232 & USB data output
function，
enable to connect with
Computer for internet transmission 。
4. Build-in-test (BIT) to detect itself under normal
condition。
5. Water proof designs to be able to use 0.6% bleach
clean the case。
6. Anti-Shock，double tiers safety case design。
7. Applicative to STAT mode (continue measurement)
function。
8. Applicative to Sound mode (replace to mercury BP
meter)。
9. FDA & CE0434 approval 。
10. GMP/ISO13485/ISO9001quality certified。
| |
| P2 SPEC.
Weight: 460 g (with batteries)
Size: 115 (W)
x 182 (L) x 76 (H) mm
Storage temperature: –20 to +50°C
Humidity: 15
to 90% relative humidity maximum
Operation temperature: -20 °C to 50°C
Display: LCD-Display (Liquid Crystal Display)
Measuring range
SYS/DIA: 25 to 280 mmHg
Pulse: 25 to
240 beats per minute
Cuff pressure display range: 0–305 mmHg
Accuracy:
Pressure within ± 3
mmHg
Pulse ±1%
or 2 beats of the reading
Power source: Rechargeable BATTERY WITH AC
100V~250V adaptor
Accessories: Cuff type for arm circumference
Cuff type : M for 23-38 cm /
L for 24~44 cm / S for 14~23
cm
Reference to standards:
EN 1060-1 /-3, NIBP -
requirements
ANSI / AAMI SP10, NIBP – requirements
CE 0434 / FDA
Build-in function Build-in test (Data loss will disable machine)
Build-in measurement times
Build-in series number
Build-in check pressure
function
Application Symbol / Sound mode/ State mode
Alarm function |
 |
|
|
|
 |
Suits for Health
checkout
In Clinic and Hospital uses |
| |
• |
ISO13485 |
| |
• |
ISO9001 |
| |
• |
CE0434 |
| |
• |
FDA
|
| |
• |
GMP |
| |
• |
The Executive
Yuan health bureau inspection
registration | |
| * Need to connect with PC
useful |
|
 |
|
|
|
|
Suits the
large-scale hospital or the teaching hospital
uses |
| |
• |
ISO13485 |
| |
• |
ISO9001 |
| |
• |
CE0434 |
| |
• |
FDA
|
| |
• |
GMP |
| |
• |
The Executive
Yuan health bureau inspection
registration | | |
| Application |
•
Hypertensive / Hypotensive Patients
screening
• The coronary artery patient
screens
• The heart valve patient to
screen
• Blood vessel Pulse Variation rate
analysis (BPV)
• patients signs for life
analysis
• Clinical Studies
• Home
monitoring
|
| Features |
| • Precision measurement
Systolic pressure, Diastolic pressure, and
Pulse. |
| • |
Measure 30 seconds hearts pulse
wave and calculates the heart rate, the
valve,
and coronary artery three parts of
heart noise. |
• Measure the heart rhythm does
not put in order.
• Automatically inflation
and deflation test.
• Build-in- test
,opening to adjust
• Memory the user or
company names
• Included the measurement
memory function
• Option for the PC computer
application software
| |
| |
* The above specification changes
not in advance notice as
necessary
| | |
